Getting Started with the gbm3 Package

The gbm3 package implements generalized boosted models, gradient tree boosting for a wide variety of statistical models and loss functions, including models commonly used in statistics, such as the Cox model, that are not usually associated with boosting. When presented with data, the gbm3 package offers the user the ability to build predictive models and explore the influence of different variables on the response, akin to a data mining or exploration task.

To get started, a user must:

have a dataset in a data.frame;
select and create an appropriate distribution object;
set the training parameters for the gbm model;
set any additional variable and fitting parameters.

Once these steps are complete, a user can fit a gbm3 model with gbmt. They can then evaluate its performance, make predictions, fit additional trees, and plot the relative influence of the predictor variables.

Example dataset

To begin, this vignette will work with simulated data where the response obeys a Bernoulli distribution and is determined by 3 predictor variables. Every row of the data corresponds to an individual observation, and random weights are assigned to these observations. These weights determine the importance of each observation in the fit. At this stage it is also assumed that the fit will be made directly to the response and no offset is supplied. If a non-zero offset is supplied, it is added to the model’s additive predictor; for example, the fitted linear predictor is offset + f(x) for distributions with a link-scale predictor. Currently the package supports responses that are numeric, factors (i.e. Bernoulli), or survival objects (more specifically, counting-process or right-censored survival objects) in the case of Cox proportional hazards models. NB: Predictor variables may have missing data (specified by NA) but the responses must have no missing observations.

# create some binomial response data - N observations
N <- 1000
X1 <- runif(N)
X2 <- runif(N)
X3 <- factor(sample(letters[1:4],N,replace=T))
mu <- c(-1,0,1,2)[as.numeric(X3)]

p <- 1/(1+exp(-(sin(3*X1) - 4*X2 + mu)))
Y <- rbinom(N,1,p) # response

# Normalized weights for each observation
w <- rexp(N)
w <- N*w/sum(w)

# Offset is set to 0
offset <- rep(0, N)

# Collate data
data <- data.frame(Y=Y,X1=X1,X2=X2,X3=X3)

Creating a gbm distribution object

The gbm3 package provides a number of distributions. To view what distributions are currently available simply call available_distributions().

available_distributions()

##  [1] "AdaBoost"  "Bernoulli" "CoxPH"     "Gamma"     "Gaussian"  "Huberized"
##  [7] "Laplace"   "Pairwise"  "Poisson"   "Quantile"  "TDist"     "Tweedie"

From the list of available distributions a default GBMDist object for each distribution can be created by calling gbm_dist and passing the desired distribution’s name as follows:

# Create a default Bernoulli
bern_dist <- gbm_dist("Bernoulli")

Certain distributions have distribution-specific parameters, such as the number of degrees of freedom associated with the distribution. These parameters are passed as arguments to gbm_dist. Distribution-specific parameters are described in the “Model Specific Parameters” vignette.

Setting training parameters

Once the data have been imported and the distribution object has been created, the next task is to specify the training parameters for the gbm3 package. These parameters are passed to gbmt in a GBMTrainParams object, which can be created with the training_params constructor. The named parameters in the constructor are as follows:

num_trees: the number of iterations to use in the fitting.
interaction_depth: the maximum number of splits in each tree. A value of 1 gives an additive model, 2 allows two-way interactions, and so on. Larger values can increase overfitting; values between 1 and 5 are usually sufficient for most applications.
min_num_obs_in_node: the minimum number of observations that a node must have to be considered when fitting a tree. The default of 10 observations is usually adequate, but it can be reduced for small datasets.
shrinkage: the learning rate applied to each tree. Smaller values generally improve predictive performance, but they may require more trees to achieve a given performance. In practice the default of 0.001 usually suffices.
bag_fraction: the fraction of the training observations randomly sub-sampled to fit a tree in each iteration. This has the effect of reducing the variance of the boosted model. The default bag_fraction=0.5 is recommended.
num_train: the number of observations to be used in training the model. This defaults to the minimum value such that the terminal nodes of a fitted tree can be created.
id: a sequence of integers specifying the id of each observation in the data. This defaults to seq_len(num_train).
num_features: the number of features randomly selected, on each iteration, from the data when growing a tree.

Once the parameters have been chosen, the appropriate object can be created. For more details on these parameters and what they represent, see The Elements of Statistical Learning by Friedman et al.

# Creating an appropriate training parameters object
train_params <- training_params(num_trees = 2000, interaction_depth = 3,
                                num_train=nrow(data), num_features = 3)

Additional variable and fitting parameters

Before fitting our boosted model there are some other parameters to consider. The monotonic relationship of each predictor with the outcome can be specified through the var_monotone parameter. In this case the relationship is assumed to be arbitrary and the parameter is unspecified. The names of the predictor variables may also be specified via var_names.

Cross Validation

Cross-validation parameters may also be provided. The number of folds is set by cv_folds; by default no cross-validation is done by gbmt. An optional vector specifying the fold for each observation can be supplied through fold_id. If the distribution is Bernoulli, cross-validation can be stratified by the response.

Parallelisation

The core algorithm can be parallelized across multiple threads by passing the output of gbmParallel() to par_details. This example does not require more than one processing thread, so it uses the default.

# Example of a gbmParallel with more threads
par_detail <- gbmParallel(num_threads = 2) # Pass to par_details in gbmt

Putting it all together

With the data defined, the distribution object created, the training parameters and additional parameters specified, it is now time to fit the model. This is done by passing these objects to gbmt along with the model formula.

# Create a gbm fit
fit <- gbmt(Y ~ X1 + X2 + X3, distribution=bern_dist, data=data, weights = w,
            offset=offset, train_params = train_params,
            cv_folds=5, keep_gbm_data=TRUE)

The keep_gbm_data flag indicates that the returned GBMFit object will contain the data passed to the fit within a GBMData object.

Default behaviour

The process outlined above is slightly cumbersome. Thankfully, gbmt provides useful defaults. If distribution is not supplied, it is guessed: currently gbmt can identify Bernoulli and Cox models, and otherwise defaults to Gaussian. weights defaults to uniform weights across all data rows, and offset defaults to 0 for all data rows. The default training parameters specify 2000 trees, an interaction depth of 3, one row per observation, half of the available observations for training, half of the training observations bagged for each tree, and all predictors available for fitting. Moreover, the weights are normalized by the routine unless the distribution is Pairwise.

# A default fit to gaussian data
# Create data
N <- 1000
X1 <- runif(N)
X2 <- 2*runif(N)
X3 <- factor(sample(letters[1:4],N,replace=T))
X4 <- ordered(sample(letters[1:6],N,replace=T))
X5 <- factor(sample(letters[1:3],N,replace=T))
X6 <- 3*runif(N)
mu <- c(-1,0,1,2)[as.numeric(X3)]

SNR <- 10 # signal-to-noise ratio
Y <- X1**1.5 + 2 * (X2**.5) + mu
sigma <- sqrt(var(Y)/SNR)
Y <- Y + rnorm(N,0,sigma)

# create a bunch of missing values
X1[sample(1:N,size=100)] <- NA
X3[sample(1:N,size=300)] <- NA

# Gaussian data
gauss_data <- data.frame(Y=Y,X1=X1,X2=X2,X3=X3,X4=X4,X5=X5,X6=X6)

# Perform a cross-validated fit
gauss_fit <- gbmt(Y ~ X1 + X2 + X3 + X4 + X5 + X6,
                  data=gauss_data, cv_folds =5, keep_gbm_data = TRUE)

Identifying the optimal iteration

A fitted model contains several performance measures that can be used to identify the optimal iteration. The package offers three methods: 'test', 'cv', and 'OOB'. The 'test' method uses performance on a held-out test set and is available only when fewer observations are used to fit the model than are present in the original data. The 'cv' method uses the cross-validation error, and 'OOB' uses the out-of-bag error estimate. The 'OOB' method is available only if bag_fraction > 0, and it tends to underestimate the optimal number of iterations. The optimal iteration, along with a performance plot, can be obtained through gbmt_performance. In these plots the cross-validation error, test-set error, and out-of-bag improvement are represented by green, red, and blue lines, respectively. The training-set error is shown as a black line, and the optimal iteration is marked with a dashed blue line.

# Use gaussian fit and determine the performance
# red line is testing error
# green line is cv error
# blue line is OOB error
best_iter_test <- gbmt_performance(gauss_fit, method='test')
best_iter_cv <- gbmt_performance(gauss_fit, method='cv')
best_iter_oob <- gbmt_performance(gauss_fit, method='OOB')

## Warning in best_iter_out_of_bag(gbm_fit_obj): OOB generally underestimates the
## optimal number of iterations although predictive performance is reasonably
## competitive. Using cv_folds>1 when calling gbm usually results in improved
## predictive performance.

Fitting additional trees

After evaluating performance, the optimal number of iterations may be equal to the num_trees value used in the fit. In that case, additional trees may be fitted to the original dataset. This does not alter the cross-validation fit, but it does update the test-set and OOB errors.

# Fit additional trees to gaussian fit and recalculate optimal number of iterations
gauss_fit_more <- gbm_more(gauss_fit, num_new_trees = 5000) # This is a large number of

## Warning in gbm_more(gauss_fit, num_new_trees = 5000): gbm_more is incompatible
## with cross-validation; losing cv results.

                                                            #extra trees!
best_iter_test_more <- gbmt_performance(gauss_fit_more, method='test')

Predictions on other data

With the model fitted and the optimal number of iterations determined, predictions can be made on new datasets with predict.

# Given additional data - of the same shape as our gaussian example
X1 <- runif(N)
X2 <- 2*runif(N)
X3 <- factor(sample(letters[1:4],N,replace=TRUE))
X4 <- ordered(sample(letters[1:6],N,replace=TRUE))
X5 <- factor(sample(letters[1:3],N,replace=TRUE))
X6 <- 3*runif(N)
mu <- c(-1,0,1,2)[as.numeric(X3)]

Y <- X1**1.5 + 2 * (X2**.5) + mu
Y <- Y + rnorm(N,0,sigma)

data2 <- data.frame(Y=Y,X1=X1,X2=X2,X3=X3,X4=X4,X5=X5,X6=X6)

# Then predictions can be made
preds <- predict(gauss_fit_more, newdata=data2, n.trees=best_iter_test_more)

Relative influence of predictors

gbm3 also provides a measure of the relative influence of each predictor in the fitted model. The influence of a variable $x_j$ is determined by summing, across all trees, the improvements from splits on that variable.

# Relative influence of predictors - both examples
print(relative_influence(gauss_fit_more, best_iter_test_more))

##         X1         X2         X3         X4         X5         X6
##  23113.963  73278.980 111233.626   1279.692   1463.666  13453.139

print(relative_influence(fit, gbmt_performance(fit, method='cv')))

##        X1        X2        X3
##  1367.828 13289.185 11919.141

Plotting the marginal effects of selected variables

In addition to relative influence, gbm3 can calculate fitted values over selected predictors and create marginal plots with plot.

# Examine the marginal effects of the first two variables - gaussian example
# Shows the fitted model predictions as a function of 1st two predictors
# with all the others integrated out
plot(gauss_fit_more, var_index = 1:2)

Additional useful functions

Finally, the gbm3 package includes several additional utility functions. A GBMFit object can be summarized and printed with summary and print, respectively. Individual fitted trees can be inspected with pretty_gbm_tree, and the loss for a given distribution can be calculated with the loss S3 method, a GBMDist object, and the appropriate data.

James Hickey

2026-07-16
